Installation and Proper Use of Aquajet Dive H2

Installation Steps

1.Remove the head cover.

2.Put the battery into the battery compartmentandconnect the cables.

3. (Optional) Place the optional clump weight on the top of battery.

Note: It is easier to dive with the clump weight installed for deep divers.

4. Put the two sealing rings on the head cover.

5. Apply appropriate amount of Vaseline to the cover seal, install the head cover and press it.

6.Lock the locks on both sides of the head cover.

7.Tighten the vent plug clockwise with an Allen wrench.

NOTE: Apply appropriate amount of Vaseline to the plug to ensure the seal.

8.Install the left and right wings to the mounting position of the fuselage.

9.The electricity display and the green light is illuminated when pressing the left wing switch and keeping the pressure down, and the propeller begins to move when pressing the right speed button, which is normal working.
NOTE: The red light is illuminated when pressing the left wing switch, which means the battery is low. You need to recharge it before use.

10.(Optional) Install an underwater camera: fix the camera to the mounting hole with a joint.

Operation Steps

1.Put the machine into the water, stretch your arms pass through the wrist strap respectively.

2.Place your left hand on the left handle, and your right hand on the right handle.

3.Your left hand press the switch ( keep pressing the switch) to power on, and your right hand press the speed button to start the machine.

4. Acceleration: The default speed of startup is the lowest, and there is a total of three gears: low speed, medium speed, high speed, followed by cycle.

5.Dive: press down with your hands and enter into a state of diving.

6.Upward float: the two hands force up, enter swimming state.

7.Loosen the switch on left hand to shut down the product.

NOTE: The sediment should be prevented from entering the body and avoiding collisions.
